2024 Kawasaki Elektrode 20FS - KAWA03051

• Chassis Management Technology: ERGO-FIT®

• Motor Type: Air-cooled, brushless, in-wheel
• Power Modes: 3 modes (High / Mid / Low)
• Max Speed by Mode - H / M / L: 13 mph / 7.5 mph / 5 mph
• Drive System: Direct hub motor
• Battery Type: Lithium-ion (in-frame)
• Battery Voltage/Capacity: 36 V 5.1 Ah (187.2 Wh)
• Battery Rated Output: 250 Watts
• Battery Running Time: 150+ minutes
• Battery Charge Time: 2.5 hours (approx)*
• Maximum Battery Charge Cycles: 500 (after which 80% of original charge capacity)

• Frame Type: Aluminum
• Front Suspension/Wheel Travel: 28.8 mm. steel fork / rigid
• Rear Suspension/Wheel Travel: Rigid
• Front Tire: 16 x 2.125
• Rear Tire: 16 x 2.125
• Front Brakes: -
• Rear Brakes: 160 mm. mechanical disc
• Handlebar Clamp Size: 22.2 mm.
• Steering Stem Size: 28.6 mm.
• Seat Post Size: 27.2 mm.

• Rake: 25 deg / 2.95 in. (75 mm.)
• Overall Length: 48.6 in. (1,235 mm.)
• Overall Width: 22.9 in. (582 mm.)
• Overall Height: 30.2 in. (767 mm.)
• Ground Clearance: 5.5 in. (139 mm.)
• Seat Height: 16.1-20.5 in. (410-520 mm.)
• Wheelbase: 32.75 in. (832 mm.)
• Curb Mass: 31.97 lbs. (14.5 kg)
• Color Choices: Lime Green
• Appropriate Rider's Age: 3~8 years old
• Rider Weight (max): 99.5 lbs. (45 kg)
• Footrest: Yes (footpeg, foldable)
• Charging power source: 110-V Single Phase AC (Home)
• Charging connector: Under the frame
• Number plate: STD

• Frame and Fork: 1 year
• Non-Electrical Components: 1 year
• Electric System Components: 90 days
• Normal Wear and Tear Items: 30 days

*Running time varies based on battery age, charge and the number of charge cycles it has had, rider weight, speed and riding conditions.

KAWASAKI CARES: Read Owner's Manual and all on-product warnings. Always wear a helmet, eye protection and proper apparel. Never ride under the influence of drugs or alcohol. Adhere to the maintenance schedule in your Owner’s Manual. ©2023 Kawasaki Motors Corp., U.S.A.

Specifications subject to change.
